46
An optional Power/Data Cable is available for the Meridian XL
from your local dealer or directly from Magellan Systems.
Keep in mind that in order to support the NMEA device, your
receiver must be operating continuously. To prevent outages due
to low batteries, external power is recommended.
Selecting Baud Rate.
BAUD RATE allows you to select the appropriate baud rate for your
external equipment. (Check the documentation of your external
equipment.) You may choose from 1200, 4800, 9600 or 19200. The
default setting is 4800.
MENU
Highlight
SETUP
Press ENTER
Highlight
BAUD RATE
Press ENTER
Use
UP/DOWN ARROWS
to select 1200, 4800, 9600,
or 19200
ENTER
Selecting Waypoint Sort
WPT SORT allows you to classify the waypoints stored in the user
waypoint catalog in alphabetical order or according to their proximity
to the present position with the closest listed first. You may choose
from ALPHABETICAL, NEAREST or ICON. The default setting is
ALPHABETICAL.
Selecting the Last Fix Interval
This function allows you to set the rate that positions are automatically
saved to the last fix buffer. The default is 10 minutes.
MENU
Highlight
SETUP
Press ENTER
Highlight
LFIX INTERVAL
Press ENTER
Use UP/DOWN ARROWS to
select OFF, 10 MINUTES,
20 MINUTES, 30 MINUTES,
1 HOUR
ENTER
Plot Setup
PLOT SETUP allows you to adjust the track orientation and track history
on the PLOT screen.
For TRACK you may select OFF, 0.1, 0.5, 1.0, or 5.0. The default setting
is 1.0. For ORIENTATION, you may select HEADING UP or NORTH UP.
The default setting is HEADING UP.
MENU
Highlight
SETUP
Press ENTER
Highlight
WPT SORT
Press ENTER
Use UP/DOWN ARROWS
to selectALPHABETICAL
NEAREST or ICON
ENTER
