Specifications
Performance:
Receiver: 12 parallel-channel receiver with quadrifilar
antenna, tracks up to 12 satellites to
compute and update position information.
Acquisition Times: Warm (within 1 hour of last use) -
Approx. 25 seconds
Cold (immediately after initialization) -
Approx 1.0 minute
Update Rate: 1 second continuous
Accuracy: Position - 49 feet (15 meters) RMS (without
Selective Availability)
Velocity - 0.12 mph RMS steady state
(without Selective Availability)
Physical:
Weight: 6.8 ounces
Housing: Waterproof Construction
Temperature: 0°C to 50°C (operating)
-10°C to 60°C (storage)
Features:
No. of Landmarks: 100 stored landmarks
No. of Routes: 1
Legs per route: 10 maximum
Power:
Source: 2 AA alkaline batteries or
3.3 VDC (±2%) 110 mA at receiver or
9-16 VDC with Magellan External Power
Cable
Battery Life: Approximately 20 hours operation
