Stream ID: specify Stream ID of 0 to 256 characters which should be
consistent with that of its sender.
■
Encryption: specify the stream encryption algorithm to ensure the data
security, options are AES-128/192/256.
■
Passphrase: specify stream key of 10 to 79 characters, which is the same as
the SRT listener.
■
Test: check the connection between the server and encoder.
■
Save: save current configuration.
■
The encoder can stream up to 6 SRT servers. If the unit streams via wired
network, the total code stream is recommended to below 24 Mbps, below
16 Mbps via wireless network.
■
Name: specify a name for current task to facilitate server management,
which will be displayed in server list.
■
Stream: choose to stream main or sub stream, which can be customized in
Encoding Parameters tab.
■
Port: specify the service port of the encoder, ranging from 8000, and 10000
to 65535. The default value is 8000.
■
Latency: options are 30, 60, 120, 500, 1000, 5000, 8000ms and the default
value is 120ms. We recommend that you set the same latency for SRT caller
and listener.
■
Bandwidth: indicate the portion of the total bandwidth of a stream required
for the exchange of SRT control and recovered packets. Available values are
■
