12
Figure 6
Figure 7
HOW TO LIGHT THE SURFACE BURNERS
1. Push in and turn the control knob counterclockwise
to the LITE position. All surface burners will click
but only the burner with control knob turned to LITE
will produce a flame.
2. After the burner ignites, turn the control knob to
the desired flame size.
NOTE: ALWAYS position cooking cookware on the
burner grate before lighting the burner.
CAUTION: The flame SHOULD NOT extend beyond the
sides or the pot or pan.
IN CASE OF POWER FAILURE
WARNING: Use extreme caution when lighting burners this way.
1. Hold a lit match to the desired burner head.
2. Push and turn the control knob to the “LITE” position.
3. Once burner ignites, adjust flame to the desired size.
MIN
MAX
OFF
LITE
