PARTES Y FUNCIONES
ACCESORIOS & PARTES DEL PRODUCTO
PANEL DE CONTROL
Figura 2
Figura 3
c
a
b
d
e
Botones de funciones
Reloj y temporizador
Controlador del quemador Controlador del horno
a. Placa de la pared posterior (1)
b. Parrilla de la superficie de
cocción de Gas (1)
c. Panel de control (1)
d. Manija de la puerta del horno (1)
e. Ventana del horno (1)
f. Parrillas del horno (2)
g. Juego de parrilla: Cuenco
& Anti salpicaduras (1)
h. Soporte antivuelco (1)
i. Pata antirresbalante (4)
j. Tornillos (2)
k. Anclajes (2)
h u j k
g
f
MIN
MAX
OFF
°F
325
300
350
400
450
Broil
OFF
°F
Conv
Fan
Light
MIN
MAX
OFF
MIN
MAX
OFF
MIN
MAX
OFF
MIN
MAX
OFF
LITE LITE LITE LITE
