9. PARTS LIST
Part no.
Part
Details
Electronic parts
FOC-101
55" LED display
FOC-102
CPU board
FOC-SD
Backup SD card
FOC-110
I/O board
FOC-103
LED driver
TMB-104
12V 5V power supply
230/115V auto switch
TMB-105
12V power supply
230/115V auto switch
FOC-104B
Complete P1 (blue) button set
including LED's, switches and buttons
FOC-104R
Complete P2 (red) button set
including LED's, switches and buttons
TMB-108
Speaker
2 in each unit
FOC-105
Wheel LED small
112 in each unit
FOC-106
Wheel LED big
8 in each unit
TMB-109
Power socket with fuse
TMB-110
Power cord
TMB-111
12cm 12V cooling fan
2 in each unit
TMB-112
Mechanical counter
2 in each unit
FOC-108
Service buttons set
set of 3
FOC-109
Amplifier
Wiring
EU1-1756
Button lights
EU1-1757 1
Coin acceptor wire - PLAYER 1
EU1-1757 2
Coin acceptor wire - PLAYER 2
EU1-1758
Mechanical counters and service buttons wire
EU2-1607 1
Bill acceptor wire - PLAYER 1
EU2-1607 2
Bill acceptor wire - PLAYER 2
EU2-1629
I/O board power
EU2-1644-2
Speakers connection
EU2-1647 1
Ticket dispenser wire - PLAYER 1
EU2-1647 2
Ticket dispenser wire - PLAYER 2
EU2-1759B
Power socket wire
EU2-1763
1,5 m power wire
EU2-1769A
Power wire (bottom lights and lower back fan)
EU2-1773-2
Light power wire (clock edge, arcs and bells)
EU2-1776
Clock LED wire
EU2-1777
Light power wire (marquee, front panel)
EU2-1778
LED driver power wire
EU3-1752
I/O board wire set
EU2-1308-2
I/O board to Main Board USB wire
TMB-113
3m HDMI cord
Deacals and decorative
FOC-301
Front panel cover
FOC-302L
Left side sticker
FOC-302R
Right side sticker
FOC-303
Panel sticker set
FOC-304
Marquee complete
FOC-305 LB
Left (blue) aluminium profile with sticker
FOC-305 RR
Right (red) aluminium profile with sticker
FOC-306
Coin acceptor cover
set of two
Mechanical parts
TMB-311
Electronic coin acceptor mounting panel
2 in each unit
TMB-401
Base wheel
4 in each unit
TMB-402
Leg leveler
4 in each unit
TMB-403
28mm lock with keys
5 in each unit
TMB-404
Fan cover
2 in each unit
TMB-405
Tickets holder
2 in each unit
TMB-406
Cashbox
2 in each unit
