Fig.14 . FLEXBOX FRONT VIEW Fig.15. FLEXBOX REAR VIEW
A
C
D
B
JTAG PORT for NEC 76F00xx
BDM PORT - FOR MOTOROLA MPC5xx
12/24 V POWER OUT
IGNITION
GND
Fig.12 FLEX LEFT SIDE VIEW
Fig.13 FLEX RIGHT SIDE VIEW
