4.3.4 OBD CONNECTION
1
2
3
4
OBD
• 1. Use the OBD cable from FLEX
• 2. Connect FLEX to the PC via USB cable
• 3. Connect the OBD cable to the diagnostic socket of the vehicle
• 4. Start the software and proceed with the vehicle search and programming
Fig.20 OBD connection illustration
