48
The user’s server/PC is equipped with a FLEX software component that will be partly
connected to the LAN and then to the internet and to the MMS back-end.
Through the back-end it is possible for MAGICMOTORSPORT technicians to not only
make changes to the website but also to manage the information received by means
of the software component installed by each MMS user on their PC.
In the event of FLEX HW/SW operation tests and checks, the user connected to the
LAN will automatically transmit the obtained data to the MMS servers. This information
will then be elaborated, processed and stored with the intent of monitoring the status
of FLEX and as well as granting constant assistance to the user.
6.2 BACK-END MMS
Interface A: PCvs Flex (CNC)
Interface B: PCvsBack End
Interface
A
Interface
B
Fig.17 connection illustration
