ID Card Printer ā€“ User Manual
7
Printer Key Components
Printer Rear Connector Panel
USB
Ethernet
DC Power
Front Stacker
(70 card capacity)
Rear Hopper
(100 card capacity)
Print Head Assembly
Front Display Panel
Blue Cleaning Roller
Rear Hopper
(100 card capacity)
Rear Connector Panel
Printer Rear View
