Magiglo Custom 18 Plus - Continuation of Installation - Total Control Model

Page 33
Figure 43, Figure 44, Figure 45 and Figure 46 show examples of how the requirements for
the physical barrier may be met.
D
W
Figure 43 – Example of physical barrier
(dimensions as stated in Table 2)
D
W
Figure 44 – Example of physical barrier
(dimensions as stated in Table 2)
D
W
50mm
Min
Figure 45 – Example of physical barrier
(dimensions as stated in Table 2)
W
D
Figure 46– Example of physical barrier
(dimensions as stated in Table 2)
