1-6-3 T2202DC
[5] DVD Main
CBA Unit
[4] DVD
Mechanism
[2] Tray Chassis Unit
(S-7)
(S-7)
Top Shield
(S-8)
(S-8)
(S-8)
[8] Deck Assembly
(S-10)
(S-9)
(S-11)
(S-11)
(S-11)
[9] Main CBA
(S-6)
(S-6)
(S-5)
(S-5)
(S-6)
[6] Sub CBA
[7] Function CBA
Fig. D2
