IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-66
Carrier Frequency
The Carrier Frequency group provides the ability to modify the drive’s output carrier frequency and
drive overload level.
Table 5-52: Carrier Frequency Parameter Settings
* Not available in VG+ (A01-02 = 3)
Parameter Display Function Range Default Model
D10-01 Heavy/NormalDuty Constant Torque/Variable Torque
Selection
0, 1 0 G+/VG+
0 Heavy Duty
1 Normal Duty
D10-02 CarrierFreq Sel Carrier Frequency Selection 1–9, A, F 1 G+/VG+
1 Fc=2.0kHz
2 Fc=5.0kHz
3 Fc=8.0kHz
4 Fc=10.0 Hz
5 Fc=12.5kHz
6 Fc=15.0kHz
7 Swing PWM1*
8 Swing PWM2*
9 Swing PWM3*
A Swing PWM4*
F User Defined Determined by D10-03 through
D10-05
D10-03 CarrierFreq Max Determines the carrier frequency
upper limit.
1.0–15.0 kHz 2.0 G+/VG+
D10-04 CarrierFreq Min Determines the carrier frequency
lower limit (V/f Control only).
1.0–15.0 kHz 2.0 G+
D10-05 CarrierFreq Gain Carrier Frequency Gain (V/f
Control only).
0–99 0 G+
CAUTION
Consult Magnetek for drive derating before modifying the D10 group
parameters. Failure to do so may result in equipment damage.
