IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-104
Pulse Train Input/Output
Pulse Input and Output provides speed control capabilities via the RP and MP terminals.
Table 5-86: Pulse Input/Output Parameter Settings
Parameter Display Function Range Default
H06-01 Pulse Input Sel Selects the function of pulse input
terminal RP.
0, 5–7 0
0 Frequency Ref Set B03-01 = 4 (pulse input) to
enable this input.
5Simple PG OLV Control with Simple PG
feedback (possible only when
using motor 1 in Hoist NLB).
6 PG Feedback PG-X3 pulse feedback into the RP
terminal coming from a Slave
drive.
7 RP Feedback Pulse feedback into the RP
terminal coming from a Slave
drive.
H06-02 Pulse In Scale Number of pulses equal to the
maximum output frequency
1000–32000 Hz 1440
H06-03 Pulse Input Gain Sets the output level when input is
100%
0.0–1000.0% 100.0
H06-04 Pulse Input Bias Sets the output level when input is
zero Hz.
-100.0–100.0% 0.0
H06-05 Pulse In Filter Sets the input filter time constant 0.00–2.00 sec 0.10
H06-06 Pulse Output Sel Selects the function of pulse
output terminal MP.
0–120 102
000 Not Used
101 Frequency Ref
102 Output Freq
105 Motor Speed
120 SFS Output
H06-07 Pulse Out Scale Item output by pulse monitor is
selected by corresponding U01-xx
value.
0–32000 Hz 1440
H06-08 Pulse Min Freq Sets the minimum frequency for
the pulse train input to be
detected. Enabled when
H06-01 = 0.
0.1–1000.0 Hz 0.5
H06-09 Pulse Dev Detect When the Pulse Input terminal RP
(H06-01) is programmed for PG
Feedback (6) or RP Feedback (7),
the pulse input from terminal RP is
compared to the pulse output of
terminal MP. If the difference is
greater than the percentage
programmed into H06-09, the
drive will fault and display
“PULSDEV” on the keypad
display.
0.0–25.5% 5.0
