IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-114
Table 5-97: Torque Detection Parameter Settings - continued
Table 5-98: Mechanical Fatigue Selection Description
Table 5-99: Torque Detection Parameter Settings - continued
Parameter Display Function Range Default
L06-05 Torq Det 2 Lvl Torque Detection 2 Level 0–300% 150
L06-06 Torq Det 2 Time Torque Detection 2 Time 0.0–10.0 sec 0.1
L06-08 Mech Fatigue Sel This function can detect an
overtorque or undertorque in a
certain speed range as a result of
machine fatigue. It is triggered by a
specified operation time and uses
the oL1 detection settings (L06-01
and L06-03).
0–8 0
0 Disabled
1 Alm Spd>L06-09
2 Alm [Spd]>L06-09
3 Flt Spd>L06-09
4 Flt [Spd]>L06-09
5 Alm Spd<L06-09
6 Alm [Spd]<L06-09
7 Flt Spd<L06-09
8 Flt [Spd]<L06-09
Setting Description
0 Mechanical Weakening Detection disabled (factory default).
1 Continue running (alarm only). Detected when the speed (signed) is greater than L06-09.
2 Continue running (alarm only). Detected when the speed (not signed) is greater than L06-09.
3 Interrupt drive output (fault). Detected when the speed (signed) is greater than L06-09.
4 Interrupt drive output (fault). Detected when the speed (not signed) is greater than L06-09.
5 Continue running (alarm only). Detected when the speed (signed) is less than L06-09.
6 Continue running (alarm only). Detected when the speed (not signed) is less than L06-09.
7 Interrupt drive output (fault). Detected when the speed (signed) is less than L06-09.
8 Interrupt drive output (fault). Detected when the speed (not signed) is less than L06-09.
Parameter Display Function Range Default
L06-09 MechFat Det Spd Sets the speed that triggers
Mechanical Weakening Detection.
When L06-08 is set for an unsigned
value, the absolute value is used if
the setting is negative.
-110.0–110.0% 110.0
L06-10 MechFat Det Time Sets the time mechanical weakening
has to be detected before an alarm
or fault is triggered.
0.0–10.0 sec 0.1
L06-11 MechFat Det Hour Sets the operation time (U01-04)
required before Mechanical
Weakening Detection is active.
0–65535 0
