IMPULSE®•G+ & VG+ Series 4 Instruction Manual - February 2017
3-7
Table 3-2: Wire Sizing for 460 V Class
Recommended Gauge (AWG)
1, 4
Model #
(-G+/VG+S4)
Continuous
HD Input
Amps
Time Delay
Input Fuse
(A)
Time Delay
Input Fuse
Class
Inverse Time
Molded/Case Circuit
Breaker (A)
3
Power Circuit Wiring
Control
Wiring
Ground
Copper
2
4001
1.8 2 CC 15 14 to 10 18 to 16 14 to 12
4003
3.2 6 CC 15 14 to 10 18 to 16 14 to 12
4004
4.4 8 CC 15 14 to 10 18 to 16 14 to 10
4005
6.0 9 CC 15 14 to 10 18 to 16 14 to 10
4007
8.2 15 CC 15 14 to 10 18 to 16 14 to 10
4009
10.4 20 CC 15 14 to 10 18 to 16 14 to 10
4014
15.0 25 CC 30 12 to 6 18 to 16 14 to 10
4018
20 30 CC 40 10 to 6 18 to 16 12 to 10
4024
29 35 J 50 8 to 6 18 to 16 10 to 8
4031
39 45 J 60 8 to 6 18 to 16 10 to 6
4039
44 50 J 70 6 to 4 18 to 16 8 to 6
4045
43 60 J 80 6 to 4 18 to 16 8 to 6
4060
58 80 J 100 4 to 2 18 to 16 6
4075
71 100 J 125 4 to 2 18 to 16 6 to 4
4091
86 125 J 175 2 to 1/0 18 to 16 6 to 4
4112
105 150 J 225 1/0 to 2/0 18 to 16 4
4150
142 200 J 300 3/0 to 4/0 18 to 16 4 to 2
4180
170 250 J 350
250
2-2/0
18 to 16 4 to 300
4216
207 300 J 400
250
2-2/0
18 to 16 2 to 350
4260
248 350 J 500
350
2-3/0
18 to 16 2 to 350
4304
300 400 J 600
350
2-4/0
18 to 16 1 to 350
4370
346 500 J 700
500
2-250
18 to 16 1 to 1/0
4450
410 700 L 900
500
2-300
4-3/0
18 to 16
1/0 to
300
4605
584 800 L 1200
2-400
4-250
4-3/0
18 to 16
2/0 to
300
4810
830 1400 L 1500 4/0 x 4P x 2 18 to 16
3/0 to
300
41090
1031 1600 L 2000 300 x 4P x 2 18 to 16
4/0 to
300
1) NFPA 70 National Electric Code 2011. 430.122(a) and Table 610-14(a) 40°C, 60-minute, copper 50°C ambient
2) NFPA 70 National Electric Code 2011. Table 250.122.
3) NFPA 70 National Electric Code 2011. Table 430.52 (selected based on motor FLA).
4) NFPA 40 National Electric Code 2011. Table 315(b)(2)(a).
