45-610 Displacer Type Liquid Level Switches and Proof-er
®
Switches
4.3 Specifications

 
 







5.93
(151)
4.29 (109)
14.62 (371)
Minimum
clearance
required
for actuation
30' (9 m)
SS
Cable
standard
1" NPT
2
1
⁄2
" NPT
20' (6 m)
Cable standard
Optional flange
C
E
B
A
G
D
F
4.38 (111)
Diameter
cut out
5.44 (138)
Bolt circle
6.56 (167)
Diameter
.36 (9) Hole
Self-tapping bolts (4)
Gasket
Flange
O-Ring
Flange
2½" NPT
connection
Lock washers(4)
➁
➂
➃
➀
➄

   
1 Handle 004-4011-001 004-0490-001
2 O-Ring Not Required 012-2205-001
3 Spring 013-2502-001
4 Cable Assembly 089-5807-001
5 O-Ring Cover Not Required 004-0489-001
6 Nut 010-2107-004 Not Required
 
