Magnetrol Eclipse 706 GWR User Manual (English)

Questions and Answers:

B
Bryan ThomasAug 3, 2025
What to do if I get a software error on my Magnetrol Eclipse 706 GWR Transmitter?
- L
  Linda WilsonAug 3, 2025
  If you encounter a software error with your Magnetrol Transmitter, start by waiting up to 10 seconds, as it might be a standard start-up message. If the issue persists, perform a complete device configuration. You may also want to check the accuracy of the level reading and compare the Dielectric Range against the EoP Dielectric reading. If the level reading is incorrect, consider replacing the transmitter electronics. Shield the transmitter from any heat source or improve air circulation. For very cold environments, insulate the transmitter. If these steps don't resolve the problem, you may need to return the transmitter to the factory for recalibration. In some cases, saving a fresh Echo Rejection Curve might help.
C
Christopher SkinnerAug 13, 2025
How to troubleshoot a software error on a Magnetrol Transmitter?
- M
  Michelle MurrayAug 13, 2025
  To address a software error on your Magnetrol Transmitter, make sure the 'Model 706 Style' probe is properly attached and the HF nut is torqued. Clean the gold pin on the transmitter and the socket on the probe. Also, check your settings, including Dielectric Range Sensitivity, EoP Thresh Value, and Sensitivity Increase. Try lowering the EoP Threshold and view the Echo Curve. Check the probe model and length settings, and set the Level Threshold to Fixed. Increase the sensitivity and view the Echo Curve. If the issue persists, verify the proper probe length for your application.
M
Matthew ChaseAug 23, 2025
What to do if I get a software error and need to report the Sequence Record number for my Magnetrol Transmitter?
- L
  loveannaAug 23, 2025
  If you encounter a software error with your Magnetrol Transmitter, report the Sequence Record number to the factory.

Magnetrol Eclipse 706 GWR Specifications

General

Type	Guided Wave Radar (GWR)
Housing Material	Aluminum or stainless steel
Application	Liquid level measurement
Frequency	1 GHz
Measurement Range	Up to 30 m
Process Temperature	-40 to 200 °C
Process Pressure	Up to 5000 psi (345 bar)
Output Signal	4-20 mA HART
Power Supply	24 V DC
Enclosure Rating	IP67
Material	316L Stainless Steel
Communication	HART, Modbus
Process Connection	Threaded, flanged, or hygienic connections
Approvals	ATEX, IECEx, FM, CSA
