Guided Wave Radar
Level Transmitter

 

705 software v3.x
 


Table of Contents

Questions and Answers

  • C
    christina70Sep 9, 2025
    Why is upper level pulse beyond probe end on Magnetrol Enhanced Model 705 Transmitter?
    • D
      David TerrySep 9, 2025
      If the apparent position of the upper level pulse is beyond the end of the probe on your Magnetrol Transmitter, check the entered Probe Length. Alternatively, change the Threshold to Fixed.
  • J
    John JacksonAug 23, 2025
    How to fix inaccurate LEVEL and AI OUTPUT values on Magnetrol Transmitter?
    • C
      cindybrownAug 23, 2025
      If the LEVEL and AI OUTPUT values from your Magnetrol Transmitter are inaccurate, the basic configuration data might be questionable. Try reconfiguring the Probe Model, Probe Mount, Probe Length, or Level Offset. Also, ensure the level is accurate and verify the EU_0% and EU_100% values.
  • B
    Brandon GriffinAug 25, 2025
    Why do LEVEL and AI OUTPUT values fluctuate on Magnetrol Enhanced Model 705 Transmitter?
    • E
      Eric ThomasAug 26, 2025
      If the LEVEL and AI OUTPUT values from your Magnetrol Transmitter are fluctuating, it may be due to turbulence. To stabilize the readings, increase the AI Block process value filter time.
  • S
    Steven WalkerAug 26, 2025
    What causes high LEVEL and AI OUTPUT readings on Magnetrol Enhanced Model 705 Transmitter?
    • M
      Mason MuellerAug 26, 2025
      If the LEVEL and AI OUTPUT values from your Magnetrol Transmitter are reading high compared to the actual level, there might be an obstruction in the tank affecting the single rod probe. To resolve this, you can increase the Dielectric Range until the obstruction is ignored or relocate the probe away from the obstruction.
  • D
    Danielle PughAug 27, 2025
    Why are LEVEL and AI OUTPUT values reading low on Magnetrol Enhanced Model 705 Transmitter?
    • P
      Patricia JohnsonAug 27, 2025
      If the LEVEL and AI OUTPUT values from your Magnetrol Transmitter are all reading low compared to the actual level, it could be due to a lower dielectric material being over a higher dielectric material, such as oil over water. In this case, select the Fixed Threshold option.
  • C
    Christopher ScottAug 29, 2025
    Why are LEVEL and AI OUTPUT values at maximum level on Magnetrol Transmitter?
    • A
      Anthony RiveraAug 29, 2025
      If the LEVEL and AI OUTPUT values from your Magnetrol Transmitter are all at the maximum level, there may be a configuration issue. For a single rod probe, increase the Blocking Distance. You can also try increasing the Dielectric Range.
  • J
    Jasmine MccormickSep 18, 2025
    Why is fiducial signal not detected on Magnetrol Enhanced Model 705 Transmitter?
    • M
      Mark JohnsonSep 18, 2025
      If the fiducial signal is not being detected by your Magnetrol Transmitter, check the connection between the probe and transmitter. Also, check for moisture on top of the probe and for a damaged gold pin in the high frequency connector. For further assistance, consult factory.
  • M
    Michelle CrossSep 18, 2025
    What does 'High Volume Fit' error mean on Magnetrol Transmitter?
    • R
      robinandersonSep 22, 2025
      If you encounter a 'High Volume Fit' error, indicating that the level is more than 5% above the highest point in the strapping table on your Magnetrol Transmitter, first verify that the strapping table is entered correctly. It's also possible that the signal amplitude may be lower than desired.
  • M
    Megan EvansSep 8, 2025
    How to reduce emulsion layer in Magnetrol Enhanced Model 705 Transmitter interface level?
    • L
      Linda HoffmanSep 8, 2025
      To address a significant emulsion layer affecting the interface level on your Magnetrol Transmitter, examine the process to reduce or eliminate the emulsion layer.
  • J
    johnsongarySep 4, 2025
    What to do for loss of level signal due to flooding on Magnetrol Enhanced Model 705?
    • C
      Carolyn AndersonSep 5, 2025
      If your Magnetrol Transmitter is experiencing a loss of level signal possibly due to flooding (Twin Rod probes only), try decreasing the level in the vessel. You could also set the Dielectric to a lower range value or replace the probe with a Model 7xR Overfill probe.

Summary

FOUNDATION Fieldbus Overview

Description

Explains FOUNDATION fieldbus as a digital communication system interconnecting devices in the field.

Benefits

Details advantages of FOUNDATION fieldbus in design, installation, operation, and maintenance.

Device Configuration

Describes the structure of FOUNDATION fieldbus devices using blocks like Resource, Function, and Transducer.

Intrinsic Safety

Covers the support for Intrinsic Safety (IS) applications and models like FISCO.

Link Active Scheduler (LAS)

Explains the role of the Link Active Scheduler (LAS) in controlling FOUNDATION fieldbus segment communication.

QuickStart Installation

Getting Started

Provides initial steps and information needed before beginning QuickStart installation procedures.

QuickStart Mounting

Guides through the physical mounting of the probe and transmitter for quick setup.

QuickStart Wiring

Details the essential wiring steps for the Eclipse transmitter during quick installation.

QuickStart Configuration

Outlines the minimum configuration steps required for the transmitter via its LCD/keypad.

Complete Installation

Unpacking

Instructions for carefully unpacking the instrument and checking contents for damage or discrepancies.

Electrostatic Discharge (ESD) Handling Procedure

Provides essential safety procedures to prevent damage to electronic components from static discharge.

Before You Begin

Covers site preparation, required equipment, and operational considerations before installation.

Mounting

Details how to mount the Eclipse transmitter to a tank using various process connections.

Installing a Coaxial Probe

Step-by-step guide for installing coaxial probes, including specific model considerations.

Installing a Twin Rod Probe

Instructions for installing twin rod probes, covering rigid and flexible types.

Installing a Single Rod Probe

Guidance for installing single rod probes, including specific model details.

Installation Guidelines

Provides guidelines for bulk solids probes, including applications and mounting recommendations.

Installing the Transmitter

Details the process of installing the transmitter, both in integral and remote configurations.

Function Blocks

Overview

Introduces the concept of Function Blocks in FOUNDATION fieldbus for process control.

Resource Block

Describes the Resource Block which contains data specific to the transmitter and firmware information.

Transducer Block

Details the Transducer Block, its parameters, and its role in probe configuration and diagnostics.

User-Calibration Parameters

Discusses user-calibration parameters, emphasizing factory calibration for optimum performance.

Analog Input Block

Explains the Analog Input (AI) block's function in making transmitter data available to other blocks.

PID Block

Describes the PID Function Block and its parameters for implementing PID control logic.

Model 705 Menu: Step by Step Procedures

Measurement Type: Level Only

Provides a step-by-step guide for configuring the transmitter for 'Level Only' measurement.

Diagnostic Parameters

Simulation Feature

Explains the Simulate feature in the Analog Input block and its activation requirements.

Reference Information

Troubleshooting

Discusses common transmitter problems, symptoms, and recommended corrective actions.

Agency Approvals

Lists agency approvals for the Model 705 transmitter, including FM, CSA, ATEX, and CE.

Specifications

Provides detailed functional and performance specifications for the Model 705 transmitter.

Parts

Lists replacement and recommended spare parts with their part numbers.

Model Numbers

Details the model number structure for transmitters and probes, including configuration options.

References

Lists external documents and resources for FOUNDATION fieldbus and system engineering.

Appendix - Transducer Block Parameters

ASSURED QUALITY & SERVICE COST LESS

Service Policy

Outlines the MAGNETROL service policy for control repair or replacement under warranty.

Return Material Procedure

Details the procedure for returning materials, including obtaining an RMA number.
