Why is the loop stuck at 4 mA on my Magnetrol Transmitter?
If the level reading on the display of your Magnetrol Transmitter is correct, but the loop is stuck at 4 mA, ensure that the HART Poll Address is set to 0. A value between 1 and 15 can cause this issue.
What to do if the level reading on the display of my Magnetrol R82 Transmitter is stuck at a value related to the blocking distance?
If the level reading on the display of your Magnetrol Transmitter is stuck at a value related to the blocking distance, it could be that the device believes the antenna is flooded. Verify the actual level. If the antenna isn't flooded, power down the transmitter, then power it back up with the level well below the antenna.
How to troubleshoot inaccurate LEVEL, % Output, and LOOP values on Magnetrol R82?
If LEVEL, % Output, and LOOP values are all inaccurate on your Magnetrol Transmitter, first check the validity of all configuration data. Also, check the DISTANCE value of the device against the manually measured distance.
What to do if LEVEL readings are consistently high or low on Magnetrol R82 Transmitter?
If the level readings on your Magnetrol Transmitter are repeatable but consistently high (or low) from actual by a fixed amount, ensure proper values for Tank Height and Sensor Offset. Check the vessel for the present liquid level. Trim Level can be used to ensure exact measurement. Reconfigure LOOP values if necessary.
What to do if level reading is locked onto a wrong value on Magnetrol R82 Transmitter?
If the level reading is locked onto an incorrect value on your Magnetrol Transmitter, it could be because the measurement engine is finding a reflection it believes is the level signal. * Check if high dielectric foam is present. * Run the Echo Rejection routine with the level below this point (or with an empty tank) to eliminate false echoes.
How to fix level reading drops at repeatable position in vessel with Magnetrol R82?
If the level reading drops out at a repeatable position in the vessel with your Magnetrol Transmitter, it is likely that multipath is cancelling the good level signal. Orient the launcher to reduce multipath by turning it 10–20 degrees (1–2 index marks) at a time until the multipath at this point disappears.
General| Brand | Magnetrol |
|---|---|
| Model | R82 |
| Category | Transmitter |
| Language | English |
Provides information on reading the manual carefully and following instructions in sequence.
Covers safety precautions for servicing electrical equipment and handling static-sensitive components.
Details the warranty period and MAGNETROL's commitment to quality assurance.
Ensures necessary equipment, tools, and information are available before starting installation.
Lists key information needed to configure operating parameters for the R82 radar transmitter.
Provides steps for mounting the transmitter/antenna and making electrical connections.
Guides on initial transmitter setup and configuration using the device's buttons.
Procedures for unpacking the instrument and handling electronic components safely.
Covers site preparation, equipment, and operational factors like distance and dielectric.
Discusses challenging applications for radar and suggests Guided Wave Radar alternatives.
Details on physically installing the transmitter and selecting an optimal mounting location.
Guidance on optimizing beam angle and minimizing reflections from obstructions.
Specific instructions for installing the transmitter in a nozzle to prevent measurement issues.
Covers mounting considerations for stillwells and open channel flow applications.
Procedures for orienting the transmitter and adjusting the launcher for optimal performance.
Launcher orientation for flow applications and troubleshooting poor echo strength.
Instructions for wiring general purpose and intrinsically safe installations.
Covers initial setup, operating parameters, shop configuration, and display interface.
Explains how to navigate menus and enter data using the transmitter's buttons.
Details methods for entering numeric and alphanumeric data via the keypad.
Covers password security and provides a step-by-step guide to the configuration menu.
Detailed breakdown of the transmitter's menu for level measurement configurations.
Detailed breakdown of the transmitter's menu for volume and level measurement configurations.
Detailed breakdown of the transmitter's menu for flow and level measurement configurations.
Details on accessing and interpreting factory parameters and diagnostic information.
Information on connecting a HART communicator and its display interface.
Menu structure for configuring the transmitter in level-only mode via HART.
Menu structure for configuring via HART for volume/level and flow applications.
Overview of the R82 transmitter, its operation, and the pulse burst radar principle.
Explanation of the ETS technology used for measuring high-speed EM energy.
Addresses common transmitter problems with symptoms and recommended corrective actions.
Details the diagnostic message hierarchy: Faults, Warnings, and Information.
Lists and explains diagnostic fault messages, their conditions, and solutions.
Lists and explains diagnostic warning and informational messages, conditions, and solutions.
Lists agency approvals (FM, CSA, ATEX) and associated entity parameters.
Lists available replacement parts and recommended spare parts for the R82.
Details the functional specifications of the R82 transmitter, including input, output, and power.
Provides key performance metrics such as linearity, measured error, and repeatability.
Specifies functional details for the encapsulated horn antenna and its ratings.
Illustrates the physical dimensions of the transmitter with aluminum and Lexan housings.
Explains the coding system used to define the R82 radar transmitter's model number.
Provides definitions for technical terms used throughout the R82 radar transmitter manual.
Outlines the service policy for controls and the procedure for returning materials.
