What does the 'Flooded?' message mean on Magnetrol eclipse Enhanced Model 705 Transmitter?
The 'Flooded?' message indicates a loss of level signal, possibly due to flooding (twin rod probes only). Decrease the level in the vessel and set the transmitter to a lower dielectric range.
What to do if LEVEL, % OUTPUT, and LOOP values fluctuate on Magnetrol Transmitter?
If the LEVEL, % OUTPUT, and LOOP values are fluctuating, it might be due to turbulence. Increase the Damping factor until the readings stabilize.
Why is level reading stuck at full scale and loop stuck at 20.5 mA on Magnetrol eclipse Enhanced Model 705 Transmitter?
If the Level Reading on the Display is stuck at full scale, and the loop is stuck at 20.5 mA, the software might believe the probe is flooded. Check the actual level. If the probe is not flooded, check for buildup or obstructions near the top of the probe and select a higher dielectric range. Also, check for condensation in the probe connection and consider adding Blocking Distance.
How to correct consistently high or low LEVEL readings on Magnetrol eclipse Enhanced Model 705 Transmitter?
If LEVEL readings are repeatable but consistently high or low from the actual level by a fixed amount, the configuration data might not accurately match the probe length or tank height. Ensure the proper Probe Model and probe length are set. You can also adjust the trim level value by the amount of noted inaccuracy.
What causes high LEVEL, % OUTPUT, and LOOP readings on Magnetrol eclipse Enhanced Model 705 Transmitter?
If the LEVEL, % OUTPUT, and LOOP values are all reading high compared to the actual level, there might be an obstruction in the tank affecting the single rod probe. Adjust the sensitivity until the obstruction is ignored, or relocate the probe away from the obstruction.
Why are LEVEL, % OUTPUT, and LOOP values reading low on Magnetrol eclipse Enhanced Model 705 Transmitter?
If the LEVEL, % OUTPUT, and LOOP values are all reading low compared to the actual level, it could be due to a lower dielectric material over a higher dielectric material, such as foam over water. Try adjusting the Threshold settings.
What triggers the 'SZ Alarm' on a Magnetrol eclipse Enhanced Model 705?
The 'SZ Alarm' (Safety Zone alarm) is triggered when the level exceeds the safety zone limit. Decrease the level in the vessel.
How to troubleshoot 'NoSignal' error on Magnetrol eclipse Enhanced Model 705?
If you are getting a 'NoSignal' error, it means no level signal is being detected. Ensure the dielectric setting is correct for the measured medium, increase sensitivity, and confirm that the probe type is proper for the dielectric of the medium.
What does EOP High mean on Magnetrol Transmitter?
If you see 'EOP High', it means the End of Probe signal is out of range. Ensure the probe length is entered correctly.
How to resolve WeakSgnl error on Magnetrol Transmitter?
If you are getting a WeakSgnl error, the signal amplitude is lower than desired. Set the transmitter to a lower dielectric range and increase the sensitivity.
General| Type | Guided Wave Radar Level Transmitter |
|---|---|
| Application | Level Measurement |
| Measurement Range | Up to 30 m |
| Accuracy | ± 3 mm (0.12 inch) |
| Output Signal | 4-20 mA HART |
| Power Supply | 12 to 42 VDC |
| Process Temperature | -196 to 400°C (-320 to 752°F) |
| Process Pressure | Up to 40 bar (580 psi) |
| Approvals | ATEX, IECEx, FM, CSA |
| Communication Protocol | HART |
| Enclosure Rating | IP66/67, NEMA 4X |
| Material | 316L Stainless Steel, Hastelloy C-276 |
| Communication | HART |
| Process Connection | Threaded, flanged |
