57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
MATERIAL OF CONSTRUCTION
7E ECLIPSE GWR probe, English unit of measure
7M ECLIPSE GWR probe, Metric unit of measure
7 P
BASIC MODEL NUMBER
O-RINGS
CONFIGURATION/STYLE
E Hygienic, 316L stainless steel (15 R
a
EP finish)
G Hygienic, AL6XN stainless steel (15 R
a
EP finish)
H Hygienic, Hastelloy C22 (15 R
a
EP finish)
2P
3
⁄4" Tri-Clover
®
type, 16 AMP Hygienic Flange (only available with 3rd digit F)
3P 1" or 1
1
⁄2" Tri-Clover
®
type, 16 AMP Hygienic Flange
4P 2" Tri-Clover
®
type, 16 AMP Hygienic Flange
5P 3" Tri-Clover
®
type, 16 AMP Hygienic Flange
6P 4" Tri-Clover
®
type, 16 AMP Hygienic Flange
9P 2
1
⁄2" Tri-Clover
®
type, 16 AMP Hygienic Flange
HYGIENIC FLANGE CONNECTIONS
PROCESS CONNECTION SIZE/TYPE
24 to 240 inches (60 to 610 cm) ➀
(unit of measure is determined by second digit of Model Number)
Examples: 24 inches = 024; 60 centimeters = 060
LENGTH
Insertion Length
Hygienic Flange
➀ Contact factory for applications requiring probe
lengths less than 24" (60 cm).
F Hygienic Single Rod (with PTFE seal)
H Hygienic Single Rod (with O-Ring seal)
1 EPDM (only available with 3rd digit H)
C
Viton
®
GF (only available with 3rd digit H)
N None (only available with 3rd digit F)
8.2 Probe
