19
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
2.6.5.2 Measurement Type: Level and Volume (Loop Control = Volume)
Display Action Comment
1
*Status*
*Volume*
*% Out *
* Loop *
Transmitter Display LoopCtrl = Volume
Transmitter default display showing: Status, Volume, % Output
and Loop values cycles every 5 seconds
2
Volume
xxx vu
Transmitter Display Transmitter displays Volume in selected units
3
% Output
xx.x%
T
ransmitter Display
T
ransmitter displays % Output measurement derived from 20 mA
span
4
Loop
xx.xx mA
Transmitter Display Transmitter displays Loop value (mA)
5
Level
xxx.x 1u
Transmitter Display Transmitter displays Level Value in selected units
6
PrbModel
(select)
Select the type of probe
used
(Example: 7xR-x)
Select from 7xF-E or 7xH-X as shown on the probe nameplate
7
PrbMount
(select)
Select the type of probe
mounting
Select Flange
8
MeasType
(select)
Select type of measurement Select from Lvl&Vol
9
LvlUnits
(select)
Select level units Select from cm, inches, feet or meters
10
Probe Ln
xxx.x lu
Enter the exact length of
probe
Note that the original probe may have been shortened by the
skid or vessel manufacturer to fit the vessel
11
Lvl Ofst
xxx.x lu
Enter desired Level reading
when probe is dry
Level Offset is the distance from the probe tip to the desired 0
level point (-90 to 300"). Refer to Section 2.6.6
12
VolUnits
(select)
Select the volume units Select from liters or gallons
13
StrapTbl
nn pnts
Enter to access strapping
table
20-point strapping table enables conversion from level to volume
(Refer to Section 2.6.7 for more information)
14
Dielctrc
(select)
Select range bounding the
dielectric constant of the
media
Select 10–100
15
Senstvty
xxx
Enter value upward or
downward to sense liquid
surface
Allows fine gain adjustment for single rod probes (this parameter
is password protected for coaxial and twin rod probes)
16
LoopCtrl
(select)
Select variable to control
loop current
Select from Level or Volume
17
Set 4mA
xxxx vu
Enter the PV value for the
4 mA point
A small transition zone (0–6" [0-15 cm)) may exist at the top/bot-
tom of the probe. See Functional Specifications Probe, Section
3.6.1
18
Set 20mA
xxxx vu
Enter the PV value for the
20 mA point
A small transition zone (0–6" [0-15 cm] ) may exist at the top/bot-
tom of the probe
19
Damping
xx s
Enter time constant of
desired damping
A Damping factor (0–10 seconds) may be added to smooth the
output due to turbulence
20
Fault
(select)
Select the loop current value
in presence of a fault
Select from 3.6 mA, 22 mA or HOLD
21
BlockDis
xx.x lu
Enter distance below refer-
ence point where level is not
sensed
Allows user to ignore level measurements near the top of the
probe
To Next Page
