Magnetrol eclipse Enhanced Model 705 User Manual

18
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
2.6.5.1 Measurement Type: Level Only (Loop Control = Level)
Display Action Comment
33
DispFact
(select)
Select Yes to display factory
parameter menus
34
History
(current status)
P
ress Enter to view history
of exceptions
D
iagnostic Display
35
Run Time
36
History Reset
Press Enter and select yes
to clear history
Similar to SZ Alarm Reset
37
HF cable
(select)
S
uperuser Parameter
S
elect from 3-foot or 12-foot (84 cm or 366 cm) remote
38
FidTicks
xxxx
Diagnostic Display Time of flight from start of ramp to fiducial
39
FidSprd
40
Fid Type
(select)
Superuser Parameter Select from positive or negative
(Selection only allowed for some probes)
41
Fid Gain
xxx
Superuser Parameter Amount of gain applied to the fiducial signal
42
Window
xxx
Factory Parameter
43
Conv Fct
xxxx
Factory Parameter Calibration parameter
44
Scl Ofst
xxx
Factory Parameter Calibration parameter
45
Neg Ampl
xxx
Superuser Password Diagnostic parameter
46
Pos Ampl
xxx
Superuser Password Diagnostic parameter
47
Signal
xxx
Diagnostic Display Indication of level signal amplitude
48
Compsate
(select)
Superuser Password Select from None, Manual, Auto
49
DrateFct
xxxx
Diagnostic Display Compsate = Auto. Velocity derating factor for Model 7xS Steam
probe
50
Targ Ampl
xxxx
Diagnostic Display Compsate = Auto. Indication of steam reference target amplitude
51
Targ Tks
xxxx
Diagnostic Display Compsate = Auto. Measured time of flight from fiducial to steam
reference target
52
Targ Cal
xxxx
Diagnostic Display Compsate = Auto. Calibrated time of flight from fiducial to target
in room temperature air
53
OperMode
(select)
Superuser Password Compsate = Auto. Select from Run, Cal, Off
54
7xKCorr
xxx
Superuser Password Distance in mm from fiducial to user reference point
(7xK probe characteristic)
55
ElecTemp
xxx C
Diagnostic Display Present temperature in electronics compartment
(degrees Celsius)
56
Max Temp
xxx C
Superuser Password Maximum electronics temperature recorded
57
Min Temp
xxx C
Superuser Password Minimum electronics temperature recorded
58
SZ Hyst
xx.x lu
Superuser Password
