57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
6.0 Parts
6.1 Replacement Parts
Item Description
Dual
Compartment
3
04 ss Single
Compartment
Housing
➀
Electronic module
HART with display (SIL 1) Z31-2835-001 89-7254-001
HART without display (SIL 1) Z31-2835-002 N/A
HART with display (SIL 2) Z31-2835-003 89-7254-003
HART without display (SIL 2) Z31-2835-004 N/A
FO
UNDATION
fieldbus with display Z31-2841-001 89-7254-002
FOUNDATION fieldbus without display Z31-2841-002 N/A
PROFIBUS PA with display Z31-2846-001 89-7254-004
PROFIBUS PA without display Z31-2846-002 N/A
➁
Terminal board
HART General Purpose (GP), Intrinsically Safe (IS), Explosion Proof (XP) Z30-9151-001 N/A
FOUNDATION fieldbus (XP) Z30-9151-003 N/A
FOUNDATION fieldbus (IS/Fisco) Z30-9151-004 N/A
➂
O-ring (Viton
®
)
(Consult Factory for alternative O-ring materials)
012-2201-237
12-2201-237
➃
Housing cover without glass 004-9193-003 36-5702-003
➄
Housing cover with glass (GP, IS)
(XP)
036-4410-001
036-4410-003
36-5702-002
N/A
Part Number
Item Description
Dual
Compartment
304 ss Single
Compartment
Housing
➀
Electronic module
HART with display (SIL 1) Z31-2835-001 89-7254-001
HART without display (SIL 1) Z31-2835-002 N/A
HART with display (SIL 2) Z31-2835-003 89-7254-003
HART without display (SIL 2) Z31-2835-004 N/A
FOUNDATION fieldbus with display Z31-2841-001 89-7254-002
FOUNDATION fieldbus without display Z31-2841-002 N/A
PROFIBUS PA with display Z31-2846-001 89-7254-004
PROFIBUS PA without display Z31-2846-002 N/A
➁
Terminal board
HART General Purpose (GP), Intrinsically Safe (IS), Explosion Proof (XP) Z30-9151-001 N/A
FOUNDATION fieldbus (XP) Z30-9151-003 N/A
FOUNDATION fieldbus (IS/Fisco) Z30-9151-004 N/A
➂
Model 7xH Hygienic Probe Rebuild Kit
2”, 316 SS with Viton O-Ring (Contact factory for other sizes)
89-4505-003
➃
Model 7xF–E Hygienic Probe Rebuild Kit
2”, 316 SS (Contact factory for other sizes)
89-4504-003
