Page #35 background image
35
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
5.2 Status Messages
Display Message Action Comment
OK None Normal operating mode
Initial None Program is Initializing, level reading held at 4 mA set point. This is a
transient condition.
DryProbe None Normal message for a dry probe. End of probe signal is being detected.
E
OP < Probe
Length
E
nd of Probe signal from a dry
probe is out of range
1
) Ensure probe length is entered correctly
2) Set transmitter to a lower dielectric range
3) Consult factory
4) Ensure proper blocking distance
EOP High End of Probe signal is out of
range
1) Ensure probe length is entered correctly
2) Consult factory (old twin rod probe being used with enhanced 705)
WeakSgnl None. Signal amplitude is lower
than desired.
1) Set transmitter to lower dielectric range
2) Increase sensitivity
Flooded? Loss of level signal possibly
due to flooding, twin rod
probes only
1) Decrease level in vessel
2) Set transmitter to lower dielectric range
3) Replace with Model 7xR Overfill probe
NoSignal No level signal being detected 1) Ensure dielectric setting is correct for measured medium
2) Increase sensitivity
3) Confirm that the probe type is proper for the dielectric of the medium
4) Consult factory
No Fid Fiducial signal is not being
detected
1) Check connection between probe and transmitter
2) Check for moisture on top of probe
3) Check for damaged gold pin on the high frequency connector
4) Consult factory
FidShift FidTicks shifted from expected
value
1) Check connection between probe and transmitter
2) Check for moisture on top of probe
3) Check for damaged gold pin on the high frequency connector
4) Consult factory
Fid Sprd Fiducial Ticks variation is
excessive
1) Check connection between probe and transmitter
2) Check for moisture on top of probe
3) Consult factory
SZ Alarm Safety Zone alarm has been
tripped, loop current fixed at
SZ Fault
Decrease level in vessel
Hi Temp Present temperature in
electronics compartment is
above +80° C
1) Transmitter may need to be moved to ensure ambient temperature
is within specification
2) Change to remote mount transmitter
