57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
4
1.0 QuickStart Installation
The QuickStart Installation procedures provide the key
steps for mounting, wiring, and configuring the Eclipse
®
level transmitter. These procedures are intended for experi-
enced installers of electronic level measurement instruments.
See Complete Installation, Section 2.0, for detailed installa-
tion instructions.
1.1 Getting Started
Before beginning the QuickStart Installation procedures,
have the proper equipment, tools, and information available.
1.1.1 Equipment and Tools
•1
1
⁄2" (38 mm) wrench. Proper tools to fit the process
connection type.
• Flat-blade screwdriver
• Digital multimeter or digital volt/ammeter
• 24 VDC power supply, 23 mA minimum
• Soft jaw wrench (to tighten electropolished rod to
process connection on model 7xH probe)
NOTE: If soft jaw wrench is not available, attach a flexible polymeric or
elastomeric hose over electropolished rod wrench flats to
tighten or loosen.
