57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
7.5 Physical
inches (mm)
Eclipse
®
Remote Configuration
4.38
(111)
8.43
(214)
4.94
(126)
45 View
Eclipse
®
Housing
(45° View)
Eclipse
®
with 7xF-E Probe
Hygienic Connection
33.00 or 144.00
(838 or 3650)
3.75
(95)
3.00
(76)
2.75
(70)
2.00
(51)
3.50
(89)
2 Holes
.38 (10) Dia.
3.08
(78)
2.12
(54)
Elect.
Conn.
Qty. 2
43°
2.53
(64)
Probe
Insertion
Length
8.94
(227)
7xF-E:
9
.25
(235)
7
xH:
Process
Connection
Electrical
Connection
Ø
0.50" (12) Rod
Ø
0.25" (6) for ¾" Triclamp
2.53
(
64)
2.17
(
55)
3.02
(
77)
4.28
(109)
4.43
(113)
45° View
