57-640 Eclipse Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
0 Viton
®
GFLT
1 EPDM (Ethylene Propylene Rubber)
2 Kalrez
®
4079
8 Aegis PF128
N None (Use with probes 7xD, 7xP, 7xF-E, 7xF-F)
7E Eclipse GWR probe, English unit of measure
7M Eclipse GWR probe, Metric unit of measure
A 316/316L stainless steel
B Hastelloy C, Configuration/Style codes A, B, D, F, G, J, P, R and T only
C Monel, Configuration/Style codes A, B, D, F, G, J, P, R and T only
E
Hygienic, 316/316L stainless steel (20 R
a
EP finish), Configuration/Style code F only,
Process connections codes 3P, 4P, 5P, and 6P only
F
PFA faced flange, 2" to 4", 150# to 300#, Configuration/Style code F only,
Process connection codes 43, 44, 53, 54, 63, 64, DA, DB, EA, EB, FA, and FB only
G
Hygienic, AL6XN stainless steel (20 R
a
EP finish), Configuration/Style code F only,
Process connections codes 3P, 4P, 5P, and 6P only
H
Hygienic, Hastelloy C22 (20 R
a
EP finish), Configuration/Style code F only,
Process connections codes 3P, 4P, 5P, and 6P only
J 316/316L stainless steel NACE construction
K
316/316L stainless steel probe and process connection, ASME B31.1 specifications (model 7xS only)
N Enlarged coaxial probe, 316/316L stainless steel probe, 2" minimum process connection
P Enlarged coaxial probe, Hastelloy C, 2" minimum process connection
R Enlarged coaxial probe, Monel probe, 2" minimum process connection
V Optional PEEK
™
spacers (for Model 7xD probe only)
W Optional Teflon
®
spacers (for Model 7xD probe only)
4 PFA insulated rod, 2" NPT process connection or larger, Configuration/Style code F only
Refer to pages 51 and 52 for selections
Refer to page 52 for selections
A Coaxial Standard
3
⁄4" process connection
or larger
Dielectric range ≥1.4
D Coaxial High Temp./High Pressure
P Coaxial High Pressure
R Coaxial Overfill
Q Coaxial Hot Water/Steam
2" process connection or larger
Dielectric range ≥10
S Coaxial Hot Water/Steam
3
⁄4" process connection
or larger
T Coaxial Interface Dielectric range ≥1.4
B Twin Rod Standard
2" process connection or
larger
Dielectric range ≥1.9
7 Twin Rod Flexible
5 Twin Rod Flexible Bulk Solid
F Single Rod Standard
J Single Rod High Temp./High Pressure
1 Single Rod Flexible
2 Single Rod Flexible Bulk Solid Dielectric range ≥4.0
