Appendix – Transducer Block Parameters
53
57-640 Eclipse Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
7.6 References
1. FOUNDATION fieldbus
™
, A Pocket Guide Ian Verhappen, Augusto Pereira
2. FOUNDATION fieldbus
™
—System Engineering Guidelines, AG–181
0 BLOCK_STRUCTURE BLOCK STRUCT
1 ST_REV ST REV
2 TAG_DESC TAG DESC
3 STRATEGY STRATEGY
4 ALERT_KEY ALERT KEY
5 MODE_BLK MODE BLK
6 BLOCK_ERR BLOCK ERR
7 UPDATE_EVT UPDATE EVT
8 BLOCK_ALM BLOCK ALM
9 TRANSDUCER_DIRECTORY XD DIRECTORY
10 TRANSDUCER_TYPE XD TYPE
11 XD_ERROR XD ERROR
12 COLLECTION_DIRECTORY COLLECT DIR
13 LEVEL Level
14 LEVEL_UNIT Level Unit
15 PROBE_LEVEL Probe Level
16 PROBE_LEVEL_UNIT Probe Level Unit
17 SENSOR_VALUE Sensor Value
18 SENSOR_UNIT Sensor Unit
19 SENSOR_OFFSET Sensor Offset
20 CAL_TYPE Cal Type
21 CAL_POINT_LO Cal Point Lo
22 CAL_POINT_HI Cal Point Hi
23 PROBE_LEVEL_LO Probe Lvl Lo
24 PROBE_LEVEL_HI Probe Lvl Hi
25 LEVEL_OFFSET Level Offset
26 SENSOR_HIGH_LIMIT Sensor Hi Lmt
27 SENSOR_LOW_LIMIT Sensor Lo Lmt
28 PROBE_MODEL Probe Model
29 PROBE_MOUNT Probe Mount
30 MEASUREMENT_TYPE Measurement Type
31 PROBE_LENGTH Probe Length
32 DIELECTRIC_RANGE Dielctric Rng
33 SENSITIVITY Sensitivity
34 BLOCKING_DISTANCE Blocking Distance
35 SAFETY_ZONE_MODE SafeZone Mode
36 SAFETY_ZONE_HEIGHT SafeZone Ht
37 SAFETY_ZONE_LATCH_RESET SZ Latch Rst
38 THRESHOLD Threshold
39 TRIM_LEVEL Trim Level
40 LOCAL_AI_DISPLAY Local AI Display
41 VOLUME Volume
42 VOLUME_UNIT Volume Unit
43 INTERFACE Interface
44 INTERFACE_UNIT Ifc Unit
45 UPPER_LIQUID_DIELECTRIC Upr Liq Diel
46 INTERFACE_THRESHOLD Ifc Threshld
47 INTERFACE_VOLUME Ifc Vol
48 INTERFACE_VOLUME_UNIT Ifc Vol Unit
49 STRAP_TABLE_LENGTH Strap Table Length
50 TABLE_VOLUME_UNIT Table Volume Unit
51 STRAPPING_TABLE_POINT01 StrapTbl Pt01
52 STRAPPING_TABLE_POINT02 StrapTbl Pt02
53 STRAPPING_TABLE_POINT03 StrapTbl Pt03
54 STRAPPING_TABLE_POINT04 StrapTbl Pt04
55
STRAPPING_TABLE_POINT05
StrapTbl Pt05
56
STRAPPING_TABLE_POINT06
StrapTbl Pt06
57
STRAPPING_TABLE_POINT07
StrapTbl Pt07
58 STRAPPING_TABLE_POINT08 StrapTbl Pt08
59 STRAPPING_TABLE_POINT09 StrapTbl Pt09
60 STRAPPING_TABLE_POINT10 StrapTbl Pt10
61 STRAPPING_TABLE_POINT11 StrapTbl Pt11
62 STRAPPING_TABLE_POINT12 StrapTbl Pt12
63 STRAPPING_TABLE_POINT13 StrapTbl Pt13
64 STRAPPING_TABLE_POINT14 StrapTbl Pt14
65 STRAPPING_TABLE_POINT15 StrapTbl Pt15
66 STRAPPING_TABLE_POINT16 StrapTbl Pt16
67 STRAPPING_TABLE_POINT17 StrapTbl Pt17
68 STRAPPING_TABLE_POINT18 StrapTbl Pt18
69 STRAPPING_TABLE_POINT19 StrapTbl Pt19
70 STRAPPING_TABLE_POINT20 StrapTbl Pt20
71 FID_TICKS Fid Ticks
72 FID_SPREAD Fid Spread
73 LEVEL_TICKS Lvl Ticks
74 INTERFACE_TICKS Ifc Ticks
75 INTERFACE_MEDIUM Ifc Medium
76 ENTER_PASSWORD Enter Password
77 NEW_PASSWORD New User Password
78 DEVICE_STATUS Device Status
79 HISTORY_MESSAGE History Message
80 HISTORY_CONTROL History Control
81 RESET_HISTORY Reset History
82 HF_CABLE HF Cable
83 FID_TYPE Fid Type
84 FID_GAIN Fid Gain
85 WINDOW_705 Window
86 CONVERSION_FACTOR Conv Factor
87 SCALE_OFFSET Scale Offset
88 NEGATIVE_THRESHOLD_AMPLITUDE NegThrsh Ampl
89 INTERFACE_THRESHOLD_AMPLITUDE IfcThrsh Ampl
90 POSITIVE_THRESHOLD_AMPLITUDE PosThrsh Ampl
91 SIGNAL Signal
92 COMPENSATION Compensation
93 DERATE_FACTOR Derate Factor
94 TARGET_AMPLITUDE Target Amplitude
95 TARGET_TICKS Target Ticks
96 TARGET_CAL Target Cal
97 TARGET_OPERATING_MODE Target OperMode
98 7XK_DISTANCE_CORRECTION 7XK Dist Corr
99 ELECTRONICS_TEMPERATURE Elec Temp
100 MAX_ELECTRONICS_TEMPERATURE Max Elec Temp
101 MIN_ELECTRONICS_TEMPERATURE Min Elec Temp
102 RESET_ELECTRONICS_TEMPERATURE Reset Elect Temp
103 SAFETY_ZONE_HYSTERESIS SafeZone Hyst
104 ECHO_SUMMARY Echo Summary
105 ECHO_DATA Echo Data
106 ECHO_DATA_INDEX EchoData Indx
107 WAVEFORM_SELECTION Waveform Selection
108 NSP_VALUE NSP Value
109 FACTORY_PARAM_1 Factory Param 1
110 FACTORY_PARAM_2 Factory Param 2
111 STEAM_CAL_MOUNT Steam Cal Mount
112 NON_VOL_STAT Non Vol Stat
113 DATE_CODE Date Code
114 MAGNETROL_SERIAL_NUMBER Magnetrol S/N
115 FIRMWARE_VERSION Firmware Ver
