57-640 Eclipse Guided Wave Radar Transmitter - FOUNDATION fieldbus
™

DG DN 50, PN 250 DIN 2527 Form E Flange ➁
DH DN 50, PN 320 DIN 2527 Form E Flange ➁
DJ DN 50, PN 400 DIN 2527 Form E Flange ➁
EA DN 80, PN 16 DIN 2527 Form B Flange
EB DN 80, PN 25/40 DIN 2527 Form B Flange
ED DN 80, PN 64 DIN 2527 Form E Flange ➁
EE DN 80, PN 100 DIN 2527 Form E Flange ➁
EF DN 80, PN 160 DIN 2527 Form E Flange ➁
EG DN 80, PN 250 DIN 2527 Form E Flange ➁
EH DN 80, PN 320 DIN 2527 Form E Flange ➁
EJ DN 80, PN 400 DIN 2527 Form E Flange ➁
FA DN 100, PN 16 DIN 2527 Form B Flange
FB DN 100, PN 25/40 DIN 2527 Form B Flange
FD DN 100, PN 64 DIN 2527 Form E Flange ➁
FE DN 100, PN 100 DIN 2527 Form E Flange ➁
FF DN 100, PN 160 DIN 2527 Form E Flange ➁
FG DN 100, PN 250 DIN 2527 Form E Flange ➁
FH DN 100, PN 320 DIN 2527 Form E Flange ➁
FJ DN 100, PN 400 DIN 2527 Form E Flange ➁
2P
3
⁄4" Tri-clover
®
type, 16 AMP Hygienic Flange
3P 1" or 1
1
⁄2" Tri-clover type, 16 AMP Hygienic Flange
4
P 2" Tri-clover type, 16 AMP Hygienic Flange
5P 3" Tri-clover type, 16 AMP Hygienic Flange
6P 4" Tri-clover type, 16 AMP Hygienic Flange
9P 2
1
⁄2" Tri-clover type, 16 AMP Hygienic Flange
4R 2" 150# ANSI Raised Face Carbon Steel Flange with Top Hat
4S 2" 300/600# ANSI Raised Face Carbon Steel Flange with Top Hat
5
R 3" 150# ANSI Raised Face Carbon Steel Flange with Top Hat
5S 3" 300/600# ANSI Raised Face Carbon Steel Flange with Top Hat
TT 3
1
⁄2" 600# Fisher
®
- Proprietary Carbon Steel (249B) Torque Tube Flange
TU 3
1
⁄2" 600# Fisher - Proprietary 316 Stainless Steel (249C) Torque Tube Flange
UT 3
1
⁄2" 600# Masoneilan
®
- Proprietary Carbon Steel Torque Tube Flange
UU 3
1
⁄2" 600# Masoneilan - Proprietary 316 Stainless Steel Torque Tube Flange
UV 3
1
⁄2" 600# Masoneilan - Proprietary Carbon Steel Torque Tube Flange with Top Hat
UW 3
1
⁄2" 600# Masoneilan - Proprietary 316 Stainless Steel Steel Torque Tube Flange with Top Hat
BA DN 25, PN 16 DIN 2527 Form B Flange ➀
BB DN 25, PN 25/40 DIN 2527 Form B Flange ➀
BC DN 25, PN 64/100 DIN 2527 Form E Flange ➁
BF DN 25, PN 160 DIN 2527 Form E Flange ➁
BG DN 25, PN 250 DIN 2527 Form E Flange ➁
BH DN 25, PN 320 DIN 2527 Form E Flange ➁
BJ DN 25, PN 400 DIN 2527 Form E Flange ➁
CA DN 40, PN 16 DIN 2527 Form B Flange ➀
CB DN 40, PN 25/40 DIN 2527 Form B Flange ➀
CC DN 40, PN 64/100 DIN 2527 Form E Flange ➁
CF DN 40, PN 160 DIN 2527 Form E Flange ➁
CG DN 40, PN 250 DIN 2527 Form E Flange ➁
CH DN 40, PN 320 DIN 2527 Form E Flange ➁
CJ DN 40, PN 400 DIN 2527 Form E Flange ➁
DA DN 50, PN 16 DIN 2527 Form B Flange
DB DN 50, PN 25/40 DIN 2527 Form B Flange
DD DN 50, PN 64 DIN 2527 Form E Flange ➁
DE DN 50, PN 100 DIN 2527 Form E Flange ➁
DF DN 50, PN 160 DIN 2527 Form E Flange ➁



➀ Configuration/Style Codes A, D, P, R & S only.
➁ Configuration/Style Codes D & P only.
 
24" to 240" (60 cm to 610 cm) (7xQ and 7xS: 180" (457 cm) maximum)
(unit of measure is determined by second digit of Model Number)
Examples: 24 inches = 024; 60 centimeters = 060


3' to 75' (1 to 22 m) – (7x2, 7x5 & 7x7 only: 5' (1.5 m) minimum)
(unit of measure is determined by second digit of Model Number)
Examples: 30 feet = 030; 10 meters = 010
