57-640 Eclipse Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
Enhanced Model 705
Eclipse Guided Wave Radar Transmitter
FOUNDATION fieldbus
™
Configuration Data Sheet
Copy blank page and store calibration data for future reference and troubleshooting.
Item Value Value Value
Vessel Name
Vessel #
Process Medium
Tag #
Electronics Serial # TROUBLESHOOTING
Probe Serial # Working Value Non-Working Value
Level
Volume (optional)
Interface (optional)
Interface Volume (opt.)
Probe Model
Probe Mount
Measurement Type
Sensor Units
Probe Length
Level Offset
Volume Units (opt.)
Strapping Table (opt.)
Dielectric
Sensitivity
Blocking Distance
Safety Zone Fault
Safety Zone Height
Safety Zone Alarm
Threshold
Interface Threshold
Level Trim
Level Ticks
A. I. Disp
Dev Addr
Interface Ticks (opt.)
Fid Ticks
<Software Version>
