The following table lists the conditions indicated in the
Device Status parameter. It also shows the affect the condition
has on PV status, Sub-Status and Limit, XD ERROR and
BLOCK ALARM are not affected by these conditions directly.
The first three conditions are Type Mode. If everything is
running normally and there are no Faults or Warnings, then
the device indicates it is “OK” an the local display and in
Device Status. If a password is entered through the local dis-
play, the Transducer Block is taken Out of Service if it is
not already and the User Access or Factory Access will be
indicated in Device Status. This will indicate to the operator
that an attempt is being made to modify a parameter value.
No indication is given on the Fieldbus network if someone
is only viewing parameters on the local display.
The next set of conditions is device faults. The device will
most likely not be able to measure level correctly if one or
more of these conditions occur. The condition will be indi-
cated in Device Status and will affect PV Status, Sub-Status
and Limit as indicated.
Mode OK 15 0x00008000 Good Non-Specific Not Limited
Mode User Access 7 0x00000080 Bad OOS Not Limited
Mode Factory Access 5 0x00000020 Bad OOS Not Limited
Fault Default Params 28 0x10000000 Bad Configuration Error Not Limited
Fault No End of Ramp 27 0x08000000 Bad Device Failure Constant Limited
Fault
Lvl<Probe Length
23
0x00800000
Bad
Sensor
Failur
e
Constant
Limited
Fault No Fiducial 21 0x00200000 Bad Device Failure Constant Limited
Fault Safety Zone FLT 20 0x00100000 Bad Non-Specific Not Limited
Fault No Signal 19 0x00080000 Bad Sensor Failure Constant Limited
Fault EOP<Probe Length 18 0x00040000 Bad Sensor Failure Constant Limited
Fault EOP High 17 0x00020000 Bad Configuration Error Not Limited
Fault High Volume Fit 16 0x00010000 Bad Configuration Error High Limited
Warning Hi Temperature 11 0x00000800 No Effect No Effect No Effect
Warning Lo Temperature 10 0x00000400 No Effect No Effect No Effect
Warning Default Cal 9 0x00000200 No Effect No Effect No Effect
Warning Initializing 4 0x00000010 No Effect Initial Value Constant Limited
Warning May be Flooded 3 0x00000008 No Effect No Effect High Limited
Warning Dry Probe 2 0x00000004 No Effect No Effect Low Limited
Warning Weak Signal 1 0x00000002 No Effect No Effect No Effect
Warning No Steam Target 6 0x00000040 No Effect No Effect No Effect
57-640 Eclipse Guided Wave Radar Transmitter - FOUNDATION fieldbus 41
