Appendix A Technical Specifications
tDynamo Technical Specifications
Reference Standards and Certifications
Identification Cards Financial Transaction Cards (ISO 7813)
AAMVA
EMV ICC Specifications for Payment Systems Ver 4.3, L1 Contact and L2 Contact
Encryption: TDEA (3DES)-CBC using DUKPT
FCC Title 47 Part 15 Class B
CE Level B EMC
UR/CUR UL Recognized
California Proposition 65 (California)
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specification 2.0, compatible with 1.1
TQM Label Certified
Physical Characteristics
Dimensions (L x W x H):
3.94 in. x 3.25 in. x 0.61 in. (100 mm x 82.5 mm x 15.5 mm)
Weight
Handheld: 3 oz (82 g)
With docking stand: 10 oz (285 g)
Supported Mounting Options:
Handheld
Lanyard
Countertop with optional docking stand
Card Read Characteristics
Magnetic Stripe Reader:
Bidirectional 3 track encrypting IntelliHead magnetic stripe reader
(MSR) with MagnePrint
Magnetic Stripe Decoding:
Financial (ISO Type B), AAMVA, or Other
ISO 7810, 7811
Acceptable Swipe Speeds:
4 inches per second to 60 inches per second
Chip Card Reader:
EMVCo L1 and L2 Contact Reader
Terminal type 21 and 24 with ODA
Terminal type 21 and 24 without ODA
Contactless Reader:
EMVCo L1 and L2 Contactless Reader
D-PAS, MCL, payWave, ExpressPay, Apple Pay
User Interface Characteristics
Status Indicators:
General Status LED (Red/Green/Blue/Amber)
Contactless Status LEDs (Green)
Display Type:
Not Applicable
Display Size (viewable area):
Not Applicable
Display Resolution:
Not Applicable
