Make sure to set the jack properly in the jacking point. Raising
the vehicle with an improperly positioned jack will damage the
underbody of the vehicle or may allow the vehicle to fall off the
jack and cause personal injury.
• Use the jack only for lifting your vehicle during wheel
changing
• Do not raise the jack with someone in the vehicle
• When raising the vehicle, do not place any objects on top of
or underneath the jack
• Raise the vehicle only high enough to remove and change
the wheel
• Usable extended height of jack is up to the yellow line/mark.
Do not raise the jack above the yellow line.
• Follow jacking instructions
• Do not start or run the engine while your vehicle is
supported by the jack
Never get under the vehicle when the vehicle is supported by
the jack alone.
Remove the wheel bolts. Lift the flat tyre straight off and place it
aside. Roll the spare wheel into position and align the holes in the
wheel with the holes on the hub. Lift up the wheel and get at least
the top bolt aligned through its hole. Wiggle the wheel and fix the
other bolts.
Re-install the wheel bolts inward and tighten by hand. Press the
wheel inward and tighten the wheel bolts further.
