© Copyright Mahindra & Mahindra Ltd. 012016
8-7
8.4.6 Head Lamp Flash
Pull the lighting control stalk (from the head lamp low beam
position) towards the steering wheel to instantaneously flash the
head lamp high beam. The head lamp flash works even when the
head lamp is OFF.
8.4.7 Head Lamp Leveling System
When the vehicle is either fully or partially loaded, it will have an
upward inclination disturbing the head lamp aiming. A correct head
lamp setting provides good visibility to the driver with minimum
inconvenience to other road users.
To properly aim the head lamp beam as per the loading on the
vehicle, use the head lamp leveling switch. This switch is located on
the right side of the steering column shroud in the instrument
panel. This switch has four positions marked as 0, 1, 2, & 3.
O
F
F
L
E
S
S
O
2
1
0
R
M
E
N
U
S
E
L
I
N
F
O
B
A
C
K
0
1
2
3
4
1
2
3
4
5
6
7
x
1
0
0
0
r
p
m
2
0
4
0
6
0
k
m
/
h
8
0
S12H16
Switch
Position
Vehicle Loading Condition
0
Driver only or Driver with front passenger
1
Driver + Front passenger + Rear seat occupied
2
All seats occupied
3
All seats occupied with luggage OR Driver with luggage at
extreme rear side.
Select the suitable switch position depending on the pay load as
advised in the table.
The headlights can only be adjusted when the low beam is
switched ON.
FEATURES AND CONTROL
