Mahindra 3616 User Manual

SPECIFICATIONS
18
CLUTCH
TYPE, DIAMETER
GEAR DRIVE ........................Dry, Single Disc, Diaphragm Type, 215mm (8.46 Inch)
HYDROSTATIC DRIVE .........Dry, Single Disc, Diaphragm Type, 215mm (8.46 Inch)
OPERATION ...........................Mechanical
MECHANICAL FRONT DRIVE (MFD)
FRONT AXLE ................................Spiral Bevel Gear Type Differential
with Bevel Gear Reductions
DIFFERENTIAL LOCK
TYPE
GEAR DRIVE .........................Controlled by Pedal on the RH Step and Mechanically
Actuated
HYDROSTATIC DRIVE ..........Controlled by Pedal on the LH Step and Mechanically
Actuated
STEERING
TYPE OF STEERING ............Hydrostatic Type
HITCH SYSTEM
TYPE .............................................Three Point, Category Ⅰ
TYPE CONTROL ...........................Positions Control
TYPE VALVE ................................Three Positions,Lift,Hold and lower
LIFTING CAPACITY AT 24"BEHIND LIFT POINT (Per ASAE S349.1)
....................780kg (1720 lbs)
TYPE OF CYLINDER ...................Single Acting Type

Mahindra 3616 Specifications

General

Engine Power	36 HP
Hydraulic System	Open center
Fuel Capacity	10.6 gallons
Engine Cylinders	3
Fuel Type	Diesel
Drive	4WD
Lift Capacity	2205 lbs
Hydraulic Remotes	1 (standard)
Transmission	8F/8R Synchro Shuttle
Displacement	166.7 cu in
