Mahindra 3616 User Manual

SAFETY/DECALS
11
Low Clearance Positions
For low clearance operation, such as operating in buildings, orchards or vineyards, the ROPS can
be lowered and secured in the down position.
No rollover protection is provided in the lowered positions and the seat belt should not be fastened.
When the low clearance operation is completed, return the ROPS to the secured upright position
for all other tractor uses and transport.
IN P O R TANT: When the ROPS frame is in the lowered position, make sure there is clearance
between the frame and hitch mounted equipment. Slowly raise the hitch to maximum height to
check for necessary clearance. For drawbar attached and/or PTO driven equipment, check for
clearance including turning corners.

Mahindra 3616 Specifications

General

Engine Power	36 HP
Hydraulic System	Open center
Fuel Capacity	10.6 gallons
Engine Cylinders	3
Fuel Type	Diesel
Drive	4WD
Lift Capacity	2205 lbs
Hydraulic Remotes	1 (standard)
Transmission	8F/8R Synchro Shuttle
Displacement	166.7 cu in
