Mahindra 3616 User Manual

SPECIFICATIONS
21
OVERALL LENGTH (TO END OF LOWER LINK)
3016 / 3616 ........................................................3080 mm (121.3 inch)
OVERALL WIDTH (TO END OF TIRE)
3016 (15x19.5) ...................................................1600 mm (63 inch)
3616 (43x16.00-20) ............................................1575 mm (62 inch)
HEIGHT (TO TOP OF ROPS)
3016 (15x19.5) ...................................................2069 mm (81.5 inch)
3616 (43x16.00-20) ............................................2145 mm (84.4 inch)
3616 CABIN (43x16.00-20) ................................2107 mm (83 inch)
WHEELBASE
3016 ..................................................................1710 mm (67.3 inch)
3616 ..................................................................1750 mm (68.9 inch)
GROUND CLEARANCE
3016 (27x8.50-15) ..............................................290 mm (11.4 inch)
3616 (28x8.50-15) ..............................................315 mm (12.5 inch)
TURNING RADIUS (WITH BRAKE ASSISTANCE)
3016 ...................................................................2400 mm (94.5 inch)
3616 ...................................................................2500 mm (98.4 inch)
WEIGHT
3016 Gear Drive (15x19.5) .................................1105 kg (2437 lbs)
3016 Hydrostatic Drive (15x19.5) .......................1115 kg (2459 lbs)
3616 Gear Drive (43x16.00-20) ..........................1160 kg (2560 lbs)
3616 Hydrostatic Drive (43x16.00-20) ................1170 kg (2566 lbs)
3616 Gear Drive CABIN (43x16.00-20) ..............1390 kg (3065 lbs)
3616 Hydrostatic Drive CABIN (43x16.00-20) ....1400 kg (3087 lbs)

Mahindra 3616 Specifications

General

Engine Power	36 HP
Hydraulic System	Open center
Fuel Capacity	10.6 gallons
Engine Cylinders	3
Fuel Type	Diesel
Drive	4WD
Lift Capacity	2205 lbs
Hydraulic Remotes	1 (standard)
Transmission	8F/8R Synchro Shuttle
Displacement	166.7 cu in
