Mahindra 3616 User Manual

INSTRUMENT/CONTROLS
27
2. ENGINE SPEED CONTROL LEVER
3. LAMP SWITCH Three position switch as follows:
4. HAZARD SWITCH
Pull the engine speed control lever to the
rearward to increase the engine speed. Push
the engine speed control lever forward to
decrease the engine speed.
ALL lamps are OFF. (Turn
signal and flasher lamps
can be turned on.)
First position clockwise
illuminates head lamps,
instrument panel and rear
red lamp.
Second position is for head
lamp high beam.
To flash the Flasher Lamps whenever the
tractor is operated or traveling on roads.
LAMP
SWITCH
HAZARD SWITCH
DECREASE
INCREASE
ENGINE SPEED CONTROL LEVER

Mahindra 3616 Specifications

General

Engine Power	36 HP
Hydraulic System	Open center
Fuel Capacity	10.6 gallons
Engine Cylinders	3
Fuel Type	Diesel
Drive	4WD
Lift Capacity	2205 lbs
Hydraulic Remotes	1 (standard)
Transmission	8F/8R Synchro Shuttle
Displacement	166.7 cu in
