23-6
Mahindra USA, Inc. All Rights Reserved.
23.8 Check Power Steering Oil Level and Leak Check
The power steering reservoir is in the rear of the engine bay, on
the driver’s side. The fluid level in the reservoir should be checked
on a level surface with the engine OFF to prevent injury from
moving parts and to ensure accurate fluid level reading. Use only
the power steering fluids recommended to help avoid damage to
the power steering system. Replacing the power steering fluid
should always be done by a ROXOR authorized dealer.
1. Start the engine and let it run until it reaches normal
operating temperature.
2. Put transmission in neutral and set parking brake.
3. Unlatch and lift the hood, then place prop rod.
4. While engine idles and with power steering cap on, turn the
steering wheel lock (left) to lock (right) a couple of times.
5. Turn the engine off.
6. Check the power steering fluid level in the reservoir.
7. The fluid level should be maintained between the MIN and
MAX lines on the side of the power steering fluid reservoir.
(Refer to the below image)
8. If fluid is low, add fluid in small amounts, remember to
replace the cap and repeat steps 1 through 5.
9. Continue to follow these steps until the level reaches the
correct operating range.
10. Always check for leaks if fluid level cannot be maintained.
Driving the ROXOR with power steering fluid below the minimum
mark will damage the steering system which would void all of your
warranty coverage.
Clean spillage from all exposed surfaces with a clean cloth to
prevent surface damage.
Maintenance Procedures
