Mahindra USA, Inc. All Rights Reserved.
23-13
13. Unlatch and lift the hood, then place prop rod.
14. Remove the oil fill cap and add up to 7.4 Quarts (7.0 Liters) of
the recommended oil.
15. Reinstall the oil fill cap.
16. Start the engine and check for leaks.
17. Stop the engine and wait for 15 seconds before removing the
dipstick. Remove the dipstick. Wipe it dry with a clean cloth.
18. Reinstall the dipstick completely. Remove the dipstick and
check the oil level.
19. Remove the oil fill cap and add oil as needed to bring the level
to the upper mark on the dipstick. Do not overfill.
20. Reinstall the fill cap. Reinstall the dipstick.
21. Dispose of used filter and oil properly.
23.16 Replace Transfer Case Oil
1. Clean the oil level plug, drain plug and surrounding area.
2. Place a container to collect oil, under the transfer case.
3. Remove the lower oil drain plug. (Refer to the below image)
4. Remove the upper oil level plug.
5. Let the oil drain out.
6. Clean and reapply thread sealant. Install and tighten the
drain plug.
7. Fill new oil through oil level plug using a funnel until it begins
to drip out.
8. Install and tighten the oil level plug.
Always dispose of drained fluid properly to prevent
environmental damage.
Maintenance Procedures
