Mahindra Thar CRDe User Manual

Repair Manual MAN-00190
THAR CRDe BS-IV MAY 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present
document, are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra
& Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
Wiping system (Brief description) Wiper motor with 2 nos. of positive loading type wipers
Speedometer :
Model and type Analog
Range
0 - 160 km/h
Major marking
20 km/h
Minor marking 5 km/h
Speedometer ratio 0.545
Ratio of Speedo drive 5/ 17
Odometer :
Make and Country of origin (if imported) M/s. Premier Instruments (PRICOL)
Type Incorporated in speedometer
Fuel tank :
Material / Nominal thickness mm EDD steel / 0.75 THK EDD steel
Capacity, Liters. 60
Brake :
Service brake (Brief description)
Dual hydraulic circuit with tandem master cylinder with
vacuum assisted servo
Auto Slack Adjuster Fitted ( Yes / No /
Optional )
Yes
ABS Fitted (Yes / No / Optional ) No
Front (Disc / Drum) 226 mm dia Disc
Rear (Disc / Drum) 282 (HNSS) dia Drum
Total braking area (Front/Rear), cm² 194 / 522
Parking brake Mechanical, Operating on rear wheels
Secondary brake Unfailed circuit of service brakes
Wheel rim :
Wheel rim Size Front/ Rear 6.5J X 16 (For 235/70 R16)
Make M/s. Wheels India or M/s. Synergies Castings
Pitch circle dia of mounting bolts mm 160 mm
Number of mounting bolts 5
Material (Steel/ Aluminum alloy etc.) Steel (Alloy optional)
Tyres :
Tyre size (Front/ Rear & Spare) 235/70 R16
Tyre size designation including ply rating /
load index / speed rating
M/s. Bridgestone
No. and arrangement of wheels
(4 + 1 Spare wheel)
Front / Rear/ Spare wheel 2 + 2/ 1
Tyre type (Radial/cross ply) (with Tube / Tube
less), size & ply rating or Speed & Load rating
Type : Radial, Tubeless
Size : 235/70R16; Ply Rating- 5
LOAD INDEX / SPEED RATING
105/ S
Dynamic rolling radius, mm,
356
Inflation pressure – Unladen in kg/cm2 / kPa
Front/ Rear 2.4/ 2.4
Inflation pressure – Laden in kg/cm2 / kPa
Front/ Rear 2.4/ 2.4
Page 9
