Mahindra Thar CRDe User Manual

Repair Manual MAN-00190
THAR CRDe BS-IV MAY 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present
document, are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra
& Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
Steering gear ratio 20:1
Wheel lock angle(deg) Inner Outer
Left 32 30
Right
32 30
Power Assistance
Type of assistance Hydraulic
Make Sona Koyo Strg. Systems Ltd.
Model RHD
Oil Specification Caltex ATF Texamatic 1278 Dexron – III,
Shell Donax TG Dexron-III
Oil capacity (l) 1 Lit.
Pressure setting (kg/cm2 / bar / kPa)
75 bar
Min turning circle diameter mm
11500
Min. turning circle clearance diameter, mm 11800
Clearance:
Minimum road clearance 200 mm
Approach angle 46 (Unladen)
Departure angle 30 (Unladen)
Ramp-over angle 15 (Unladen)
Suspension :
Type and description (Leaf / Coil / Air / Semi-
pneumatic / Torsion bar)
Front IFS with Torsion bar
Rear Leaf Spring
Type of spring Semi elliptical Leaf Spring
Stack height, at center
Rear: 48 mm
Width at the center point / stack point
Rear: 63.5 mm
Flat length
Rear: 1219 ±3 mm
Free camber Rear: 115 ±5 mm
No. of leaves Left Right
No. of leaves 6 6
No. of spacers 4 4
Suspension- Shock absorber :
Type and Number
Front Hydraulic Double Acting, Telescopic, 2 Nos.
Rear Hydraulic Double Acting, Telescopic, 2 Nos.
Suspension- Stabilizer :
Front / Rear Provided/ N.A.
Chassis frame :
Type
Ladder type with steel side member,
Five intermediate cross-members,
Front and Rear Bumper Bars
Electrical system :
System voltage, V 12 V
Battery rating, Ah 70 Ah
Wiper motor Rack & Pinion Type, Two Speed
Page 8
