Mahindra Thar CRDe User Manual

Repair Manual MAN-00190
THAR CRDe BS-IV MAY 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present
document, are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra
& Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
Type Hypoid
Reduction ratio 4.3 : 1
Differential type Hypoid
Final Drive ratio
4.3 : 1 (2WD) & 10.66 : 1 (4WD)
Gear ratio Gear box ratio Overall ratio
1st 3.78 : 1 16.25
2nd 2.09 : 1 8.98
3rd 1.38 : 1 5.93
4th 1.00 : 1 4.30
5th 0.79 : 1 3.39
Reverse 3.52 : 1 15.13
Number of axles :
Steered / Non Steered
Steered: Front, Non Steered: Rear
Driven Both
Non-driven N. A.
Front axle :
Type Full floating hypoid type
Toe-in/ Toe out mm
12' to 18' at wheel rim per wheel, Total Toe in 1 to 3
mm
Camber angle
0'-1º50' (Difference between LH and RH <20')
Caster angle 2.75+/- 1º (Difference between LH and RH <1º)
King pin angle 10.6 ± 1.0°
Rear axle :
Type ( Single / Tandem / Tridem / Multi ) Semi-floating hypoid type
Steering system :
Type (Manual / Power assisted – Hydraulic /
Power assisted – Electric / Other)
Hydraulic power assisted
Steering wheel
Position(center/offset) Offset
Outside dia mm 406
Number of spokes. 3
Steering column Clamped on suspended pedal and on body
Make Sona Koyo steering system
Type / Model RHD
Intermediate shaft
Make Sona Koyo steering system
Type / Model Intermediate shaft with two UJ connections
Maximum No. of rotation of steering wheel
from lock to lock
3.5
Mounting arrangement of Steering column Clamped on suspended pedal and on body
Offset of the steering column with respect to
the seat
70.8 mm
Steering Gear
Type of steering gear (Re-circulating ball /
Worm & Roller / Rack & Pinion / Others)
Rack and pinion, hydraulic power steering
Make
M/s Rane Madras Ltd.
Page 7
