Repair Manual MAN-00190
THAR CRDe BS-IV MAY 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present
document, are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra
& Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
Vehicle Specification
• Refer following chart for THAR CRDe (BS-III & BS-IV) vehicle general specifications data –
PARAMETER MM 540 THAR CRDe
Vehicle Dimensions :
Wheel base, mm 2430
Overall width, mm 1710
Overall length, mm 3920
Overall height, mm 1930
Min. ground clearance, mm
Vehicle Weights :
Maximum GVW, kg (for rigid vehicles) 2200
(for articulated / combination vehicles)
N. A.
Maximum FAW, kg 1100
Kerb weight with 90% fue l(with spare wheel ,
tools, etc.), kg
1670
Maximum gradeability in 1st gear 30º
Seating :
Seating capacity D+6
Transmission :
Type (Manual/Automatic/semi-automatic) Manual
Clutch Type (wet/Dry/Single plate/ Multiplate
/ Hydraulic)
Dry - Single Plate
Gear box 5-Speed
Type Manual, All Gear Synchromesh
Model name (if any). NGT530R
Gear shifting control system (Sketch showing
gear shifting arrangement)
Floor Shift,
refer illustration
No. of gears 5-Forward, 1-Reverse
Gear ratio
High 1.00 : 1
Low 2.48 : 1
Final Drive Front / Rear / Both Rear (2WD)/ Both (4WD)
To Next Page
