91
CONNEC-
TOR NO
CONNECTOR
DESCRIPTION
PIN NO FUNCTION
18 PERMANENT BATTERY SUPPLY
1 BATTERY SUPPLY 1
3 BATTERY SUPPLY 2
5
BATTERY SUPPLY 3
16 IGNITION
4 BATTERY GROUND 2
6
BATTERY GROUND 3
2 BATTERY GROUND 1
14.1.1.3 DIAGNOSTIC PROCEDURE
STEP 1 – CHECK THE FUSES
PRE CONDITION
• Ignition OFF
TEST PROCEDURE
• Check the condition of fuse F42, F6, F20, F27, F35, F46, F1, F2 & F50
ACCEPTANCE CRITERIA
• Are all the fuses are OK
ACTION TO BE TAKEN
OK NOT OK
• GO TO STEP 2
• Replace the blown fuse
STEP 2 – CHECK THE BATTERY VOLTAGE
PRE CONDITION
• Ignition OFF
• Remove the EMS ECU main relay
• Ignition ON
TEST PROCEDURE
• Check the battery voltage at pin 157 and pin 158 of C 144 (EMS ECU main relay)
ACCEPTANCE CRITERIA
Diagnostic Manual
XUV700 (Diesel)
UICU
MAN-01065
OCT - 2021/Rev 1
