MAI INTERNATIONAL

GmbH

SPARE PARTS "FIGURE I"

Pos. P/N Description

1 152756 Switch cabinet

1.01 w/o Fig. 152521 Cover for switch cabinet

2 150739 Auxiliary contactor 400V/50-60Hz

3 152759 Motor protection switch PKM0-16

4 104044 Motor protection relay PKZM 0-1,6, 1-1,6A

5 102126 Phase sequence relay RM4TG20

6 151762 Auxiliary contactor 42 V/50 Hz

7 151147 Clamp 4mm²

8 151739 Power Contactor Vanne LC1D18D7 7,5 kW 42V 50-60 Hz

8.01 w/o Fig. 152232 bond bridge for reverse contactor combination LAD-9R1

9 152377 Motor protection relay 9-13A LRD-16

10 100490 Transformer ET 0,1 400/ 42 V

11 102281 Control relay CA2KN31E7

12 152730 Motor protection relay 1,2-1,8A

13 152729 Reversing contact 42VAC, 9A
