MAI INTERNATIONAL
GmbH
SPARE PARTS "FIGURE J"
Pos. P/N Description
1 152756 Switch cabinet
1.01 w/o Fig. 152521 Cover for switch cabinet
2 153263 Auxiliary contactor 220V/50-60Hz
3 153255 Motor protection switch 32A
4 104044 Motor protection relay PKZM 0-1,6, 1-1,6A
5 102126 Phase sequence relay RM4TG20
6 151762 Auxiliary contactor 42 V/50 Hz
7 151147 Clamp 4mm²
8 151741 Power Relay LC1D32D7 15 kW 42V 50-60 Hz
9 153257 Motor protection relay 23-32A LRD-32
10 101693 Transformer 42 V
11 102281 Control relay CA2KN31E7
12 153407 Motor protection relay 2,6-3,7A
13 152729 Reversing contact 42VAC, 9A
