SPARE PARTS "FIGURE K"
Pos. P/N Description
1 103159 Gauge bow for pump outlet
2 100275 Glycerine gauge 100 bar
3 101411 Reduction sleeve 1/2" ET - 1/4" IT
4 100254 Washer M20
5 153233 Plate for pump outlet galvanized
6 102820 Diaphragm ø35 for pressure control gauge
7 153229 Pump outlet "L" galvanized M400NT
7 153492 Pump outlet "M" galvanized M400NT
8 100279 MAI-Quick coupling NW25 1" "male"
8 153516 MAI-Quick coupling NW25 6/4" "male"
8 151097 Kamlok coupling NW25 "male"
8 100231 MAI-Quick coupling NW35 6/4" "male"
9 153640 Pump outlet "M" galvanized M400NT Japan
